Meihanda Phantom W Series Fruit Cart 7005

Phantom Series Road Bikes – Technical Specifications Comparison

Component/Model	Phantom W700	Phantom W750	Phantom W800	Phantom W900
Frame Material	7005 Aerospace Aluminum Alloy	7005 Aerospace Aluminum Alloy	7005 Aerospace Aluminum Alloy	7005 Aerospace Aluminum Alloy
Fork	T800 Carbon Fiber Fork	T800 Carbon Fiber Fork	T800 Carbon Fiber Fork	T800 Carbon Fiber Fork
Drivetrain System	– Shifters: LanTu GRT New Version / Suruida 680 Gravel Road Groupset (1×12)	– Shifters: Shimano 105 R7120 Hydraulic STI Levers – Derailleurs: Shimano 7100 Front/Rear	– Shifters: Luanfeng 13-Speed Electronic Shifting Kit	– Shifters: Shimano GRX600 Hydro Lever – Rear Derailleur: Shimano GRX812
Braking System	LanTu Hydraulic Disc Brakes / Suruida Hydraulic Disc Brakes	Shimano 7170 Hydraulic Disc Brakes	Luanfeng Hydraulic Disc Brakes	Shimano RX400 Hydraulic Disc Brakes
Wheelset	– Rims: Aluminum Alloy Aerodynamic Rims – Tires: CST 700×40c Folding Bead	– Rims: Aluminum Alloy Aerodynamic Rims – Tires: CST 700×40c Folding Bead	– Rims: Aluminum Alloy Aerodynamic Rims – Tires: CST 700×40c Folding Bead	– Rims: Aluminum Alloy Aerodynamic Rims – Tires: CST 700×40c Folding Bead
Handlebar & Stem	– Bars: Aluminum Alloy Flared Drop Bar – Stem: 31.6mm Aluminum Alloy	– Bars: Aluminum Alloy Flared Drop Bar – Stem: 31.6mm Aluminum Alloy	– Bars: Aluminum Alloy Flared Drop Bar – Stem: 31.6mm Aluminum Alloy	– Bars: Aluminum Alloy Flared Drop Bar – Stem: 31.6mm Aluminum Alloy
Seatpost	31.6mm Aluminum Alloy Dual-Rail Seatpost	31.6mm Aluminum Alloy Dual-Rail Seatpost	31.6mm Aluminum Alloy Dual-Rail Seatpost	31.6mm Aluminum Alloy Dual-Rail Seatpost
Crankset	Haomeng 42T Hollowtech Aluminum One-Piece Crank	Yuyong PR2 34/50T DUB Crank	Haomeng 42T Hollowtech Aluminum One-Piece Crank	Haomeng 42T Hollowtech Aluminum One-Piece Crank
Cassette	Rihu 11-50T Splined Cassette	Rihu 11-32T Splined Cassette	Rihu/Sujie 11-52T Splined Cassette	Rihu 11-42T Splined Cassette
Bottom Bracket	T47 Press-Fit Threaded BB	T47 Press-Fit Threaded BB	T47 Press-Fit Threaded BB	T47 Press-Fit Threaded BB
Chain	KMC X12 12-Speed Chain	KMC X12 12-Speed Chain	KMC X12 12-Speed Chain	KMC X11 11-Speed Chain

The Phantom W Series – Gravel Performance Redefined

The Meihanda Phantom W Series is a family of high-performance gravel bikes engineered for riders who demand versatility, durability, and speed across mixed terrain. Whether you’re grinding up steep gravel climbs, commuting through the city, or embarking on a multi-day bikepacking adventure, the Phantom W Series delivers the performance and reliability you need. Available in four distinct models – W700, W750, W800, and W900 – there’s a Phantom for every rider and every budget.

7005 Aerospace Aluminum Frame – Lightweight and Durable

At the core of every Phantom W Series bike is a 7005 aerospace-grade aluminum alloy frame. 7005 aluminum is widely regarded as one of the best frame materials for gravel and adventure bikes, offering an exceptional strength-to-weight ratio. Unlike standard 6061 aluminum, 7005 alloy provides:

• Superior strength – Greater tensile strength for demanding off-road conditions

• Excellent fatigue resistance – Built to withstand years of rough riding

• Lightweight construction – Keeps the bike agile and responsive

• Natural corrosion resistance – Ideal for all-weather riding

7005 aluminum frames are prized by both professional builders and enthusiasts for their ability to deliver a lively, responsive ride feel without the premium price tag of carbon fiber.

T800 Carbon Fiber Fork – Smooth Out the Rough Stuff

Up front, the Phantom W Series features a T800 carbon fiber fork. This high-modulus carbon fork absorbs road vibrations and trail chatter, significantly reducing fatigue on long rides. The carbon construction also saves weight over aluminum forks, improving front-end responsiveness and steering precision. Whether you’re navigating washboard gravel roads or potholed city streets, the T800 carbon fork keeps you comfortable and in control.

Four Models – Choose Your Perfect Setup

The Phantom W Series offers four distinct configurations to match your riding style and budget:

W700 – The Versatile All-Rounder

The entry-level W700 features a choice of LanTu GRT or Suruida 680 Gravel 1×12 drivetrain, offering a wide gear range from 11 to 50 teeth for tackling steep climbs and fast descents alike. The 42T Haomeng Hollowtech aluminum crankset provides efficient power transfer. Hydraulic disc brakes from LanTu or Suruida deliver reliable stopping power in all conditions.

W750 – Shimano 105 Performance

The W750 steps up to the legendary Shimano 105 R7120 24-speed groupset (2×12), featuring hydraulic STI levers for precise, effortless shifting. The Shimano 7170 hydraulic disc brakes provide industry-leading stopping power and modulation. Paired with a Yuyong PR2 34/50T DUB crankset and Rihu 11-32T cassette, this model delivers smooth, reliable performance for serious gravel riders.

W800 – Electronic Shifting Innovation

The W800 brings cutting-edge technology to gravel riding with the Luanfeng 13-speed electronic shifting system. Electronic shifting delivers instant, precise gear changes at the push of a button, eliminating cable stretch and maintenance concerns. The Rihu/Sujie 11-52T cassette offers an enormous gear range for the steepest climbs. Luanfeng hydraulic disc brakes complete the package.

W900 – Shimano GRX Adventure Spec

The top-tier W900 is equipped with Shimano GRX600 hydraulic levers and a Shimano GRX812 rear derailleur – Shimano’s dedicated gravel-specific groupset. The GRX system is engineered specifically for mixed-terrain riding, with optimized ergonomics, improved chain retention, and a 1×11 drivetrain that keeps things simple and reliable. Shimano RX400 hydraulic disc brakes provide exceptional stopping power. The Haomeng 42T Hollowtech crankset and Rihu 11-42T cassette offer the perfect gearing for gravel adventures.

Premium Components Throughout

All Phantom W Series models share a commitment to quality components:

• Wheelset: Aluminum alloy aerodynamic rims with CST 700×40c folding bead tires – the ideal width for gravel riding

• Handlebar: Aluminum alloy flared drop bars for increased control and comfort on rough terrain

• Stem: 31.6mm aluminum alloy stem

• Seatpost: 31.6mm aluminum alloy dual-rail seatpost

• Bottom Bracket: T47 press-fit threaded BB – a modern standard known for durability and easy maintenance

• Chain: KMC X12 12-speed or X11 11-speed chain

Aerodynamic Rims & Gravel Tires

The aluminum alloy aerodynamic rims are designed to cut through the wind while maintaining the durability needed for gravel riding. Wrapped in CST 700×40c folding bead tires, these wheels offer the perfect balance of rolling efficiency and comfort. The 40mm width provides a plush ride that smooths out rough surfaces while maintaining excellent traction on loose gravel.

Color Options

The Phantom W700 is available in a stunning range of finishes:

• Matte Black – Sleek and stealthy

• Silver – Clean and classic

• Sky Green – Fresh and adventurous

• Chameleon – A striking color-shifting finish

The W750 and above models are available in Matte Black and Silver.

Why Choose the Phantom W Series?

• 7005 aerospace aluminum frame – Premium material at an accessible price

• T800 carbon fiber fork – Vibration damping and weight savings

• Four models – Find the perfect spec for your budget and needs

• 12/13-speed drivetrains – Wide gear range for any terrain

• Hydraulic disc brakes – Reliable stopping power in all conditions

• CST 700×40c tires – The ideal gravel tire width

• T47 bottom bracket – Modern, durable, and easy to service

• Multiple color options – Express your personal style

The Phantom W Series Difference

Premium gravel bikes from major brands with 7005 aluminum frames, carbon forks, and 12-speed drivetrains often cost $2,500–$4,000 or more. The Meihanda Phantom W Series delivers the same premium materials and component specifications – 7005 aluminum, T800 carbon fork, hydraulic disc brakes, and 12-speed gearing – starting at just $1,199. Whether you choose the versatile W700, the Shimano-equipped W750, the electronic-shifting W800, or the GRX-spec W900, you’re getting exceptional value without compromise.

Find your perfect Phantom W Series gravel bike today – starting at $1,199!
